8.5 Digit Digital Multimeter
The intent of the 3458A/AC ILC/PT is to provide a means for the participant to determine the appropriateness and effectiveness of participant practices, training, and measurement uncertainty relating to calibration of a 8.5 digit Digital Multi-function Meter (DMM).
This ILC/PT Kit contains a 8.5 digit DMM. Participants will use their lab practices to perform 15 measurements of voltage and current. Measurement values will be appropriate for calibration of similar devices.
Participants are expected to be familiar with, and have appropriate lab equipment and measurement uncertainties for calibration of similar devices.
Artifact in kit: HP 3458A, 8.5 Digit DMM
*Premium Kit enrollment: $795. Discounts are not applicable to Premium Kits.
**TRAVEL KIT: This kit travels with the 3458A/DC, should you decide to participate in the 3458A/DC, there is an additional $300 fee per submittal.
8.5 Digit Digital Multimeter
The intent of the 3458A/DC ILC/PT is to provide a means for the participant to determine the appropriateness and effectiveness of participant practices, training, and measurement uncertainty relating to calibration of a 8.5 digit Digital Multi-function Meter (DMM).
This ILC/PT Kit contains a 8.5 digit DMM. Participants will use their lab practices to perform 15 measurements of voltage and current. Measurement values will be appropriate for calibration of similar devices.
Participants are expected to be familiar with, and have appropriate lab equipment and measurement uncertainties for calibration of similar devices.
Artifact in kit: HP 3458A, 8.5 Digit DMM
*Premium Kit enrollment: $795. Discounts are not applicable to Premium Kits.
**TRAVEL KIT: This kit travels with the 3458A/AC, should you decide to participate in the 3458A/AC, there is an additional $300 fee per submittal.
AC Watt Transducer Kit
The intent of this ILC/PT is to provide a means for the participant to determine the appropriateness and effectiveness of participant practices, training, and measurement uncertainty relating to calibration of a AC Watt Transducer.
This ILC/PT Kit contains a AC Watt Transducer. Participants will use their lab practices to perform 5 measurements of voltage and current. Measurement values will be appropriate for calibration of similar devices.
Participants are expected to be familiar with calibration of, have appropriate lab equipment and have measurement uncertainties appropriate for calibration of similar devices.
Artifact in kit: Ohio Semitronics, GW5-020E
Attenuators Set of 5 Power Meter
The intent of this ILC/PT is to provide a means for the participant to determine the appropriateness and effectiveness of participant practices, training, and measurement uncertainty relating to the calibration of RF Attenuators between 1 and 26.5 GHz.
This ILC/PT contains a set of 5 attenuators; each is a 20 dB, 3.5 mm device.
Participants will utilize their practices to perform 60 separate attenuation measurements, as they connect each device, perform dB Loss measurement at a predetermined four frequencies, remove the device, rotate the device per instructions, reconnect, perform measurements at the same four frequencies, remove and rotate the device again and reconnect to perform a third set of measurements. The average of the three measurements at each frequency is reported, and the entire process is repeated with the remaining 4 attenuators.
Capacitors
The intent of CAPACITANCE-1409 is to provide a means for the participant to determine the appropriateness and effectiveness of participant practices, training, and measurement uncertainty relating to the calibration of Fixed Capacitors.
This ILC/PT Kit consists of seven GenRad capacitors in the range of 0.001 µF to 0.5 µF. Participants are expected to be able to characterize each capacitor and report the measured values within their reported uncertainties. The frequency of test will be at 1 KHz.
Participants are expected to be familiar with, and have appropriate lab equipment and measurement uncertainties for calibration of similar devices.
Artifacts in Kit: Set of 7, GenRad Model 1409 Standard Capacitors
